3D Metal Printer
Keywords: Metal additive manufacturing, SLM 3D printer, DMLS, industrial 3D printing
3D metal printers use advanced additive manufacturing technology to create strong, complex metal parts layer-by-layer. These printers enable rapid prototyping, lightweight design, and on-demand production of high-precision components.
key Features of Metal 3D printers
- Support for materials such as stainless steel, titanium, aluminium, Inconel, and tool steels
- Technologies include SLM (Selective Laser Melting), DMLS, EBM, Binder Jetting
- Ability to manufacture complex geometries not possible with CNC machining
- Reduced lead time, minimal wastage, and superior design flexibility
Metal 3D printing is widely used in aerospace, EV components, medical implants, tooling, and high-performance manufacturing.
Metal 3D printing is widely used in aerospace, EV components, medical implants, tooling, and high-performance manufacturing.
HI PERFORMANCE LASER 3D METAL PRINTER – SMID100
HI PERFORMANCE WITH AFFORDABLE PRICE LASER BEAM POWDER BED FUSION 3D METAL PRINTER
Machine Specifications
| Specification | |
|---|---|
| Laser Type | Ytterbium Fiber Laser 200 / 300 W |
| Laser Wavelength | 1070 nm |
| Build Volume | 100 × 100 × 100 mm |
| Process Type | Laser Beam Powder Bed Fusion |
| Build Speed | 1 – 20 cc/hr |
| Focus Spot Size | 50 – 100 µm |
| Layer Thickness | 10 – 100 µm |
| Accuracy | ±50 µm |
| Control System & Software | |
| Software Tools | BeamConstruct / RepliSLS3D |
| Operating System | Windows 10 |
| Input File | STL |
| Network | Ethernet |
| Service Requirement | |
| Electrical | 440V / 3 KVA |
| Dimensions | 1700 × 1500 × 1800 mm |
| Weight | 700 kg |
| Compressed Air | 6–8 kg/cm² |
| Gas | Nitrogen / Argon |
| Powder Options |
Aluminum Si10Mg Bronze Copper C18150 SS 316L Maraging Steel Titanium Ti64 |
RV MACHINE TOOLS SMID RANGE 3D METAL PRINTERS POWDER BED LASER BEAM FUSION WITH CUTTING EDGE TECHNOLOGY TO OFFER QUALITY PARTS WITH AFFORDABLE PRICE
TTHE SMID100 3D PRINTER MEETS THE SPEED AND QUALITY PART WITH HI PERFORMANCE IPJ MAKE LASER TECHNOLOGY TO MEET BOTH RESEARCH AND DEVELOPMENT APPLICATIONS
SMID100
- Hi Performance IPG Laser
- High Speed & Precision Scan Head
- Quality F-Theta Lens
- User Friendly Slicing Software
Hi PERFORMANCE LASER 3D METAL PRINTER SMID150
HI PERFORMANCE WITH AFFORDABLE PRICE LASER BEAM POWDER BED FUSION 3D METAL PRINTER
Machine Specification
| Specifications | |
|---|---|
| Laser Type | Ytterbium Fiber Laser single 200,300,400 Watts |
| Laser Wavelength | 1070 nm |
| Build Envelope (L x W x H) | 150 x 150 x 150 mm |
| Process Type | Laser Beam Powder Bed Fusion |
| Build Speed | 1—20 cc/hr |
| Focus Spot Size | 50 m – 100 m |
| Layer Thickness | 10m- 100 m |
| Accuracy | ±50 µm/td> |
| Material Deposition | Re coater blade |
| Material Loading | Manual |
| Control system and software | |
| Software Tools | BeamConstruct PRO / RepliSLS3D PRO |
| Control software | Intelli IO |
| Operating System | Windows 10 |
| Input date file | STL |
| Network type | Ethernet |
| Service Requirement | |
| Electrical | 440v/ 3 kva |
| Machine Dimensions | 1700 x 1500 x 1800 mm |
| Weight | 700 kg |
| Compressed Air | 6-8kgcm2 |
| Nitrogen or Argon | 6-8kgcm2 |
| Powder Options |
Aluminum Si10Mg Bronze, Copper(C18150) Stainless steel 316L Maraging steel Titanium Ti64 |
RV MACHINE TOOLS SMID RANGE 3D METAL PRINTERS POWDER BED LASER BEAM FUSION WITH CUTTING EDGE TECHNOLOGY TO OFFER QUALITY PARTS WITH AFFORDABLE PRICE
THE SMID100 3D PRINTER MEETS THE SPEED AND QUALITY PART WITH HI PERFORMANCE IPJ MAKE LASER TECHNOLOGY TO MEET BOTH RESEARCH AND DEVELOPMENT APPLICATIONS
SMID100
- Hi Performance IPG Laser
- High Speed & Precision Scan Head
- Quality F-Theta Lens
- User Friendly Slicing Software
